Blackmagic Design | SKU: SWATEMMINIBPRISO

Blackmagic Design ATEM Mini Pro ISO HDMI Live Stream Switcher

Name: Blackmagic Design ATEM Mini Pro ISO HDMI Live Stream Switcher
Brand: Blackmagic Design
SKU: SWATEMMINIBPRISO
Price: 2049.00 AED
Availability: InStock

Dhs. 2,049.00

Tax included Shipping calculated at checkout.

Delivery and Shipping

We offer free delivery across the UAE for orders over 250 AED.

For orders below this amount delivery fee of AED 29.00 will apply.

• Dubai: Delivery within 1 working day.

• Rest of UAE: 1-2 working days.

• GCC: We also provide shipping to countries within the GCC, but delivery times may vary depending on location.

Credit card & Tabby
Cash on Delivery (COD) is available only for orders within the UAE.

Description

Key Features

4-Channel Live Stream HDMI Switcher
Program and 4 x Input ISO Recording
Generates DaVinci Resolve Project
Live Tally, Stream, and Record Status
Record Button, Channel Preview Multiview
2-Channel Digital Audio Mixer per Source
HDMI Output, Ethernet ATEM Control
Media Player, Computer Input Support
Upstream and Downstream Keyers
DVE Transition, Chroma/Luma Keyers

Overview

The ATEM Mini Pro ISO HDMI Live Stream Switcher from Blackmagic Design is a four-input live production switcher with an integrated control panel designed for multicamera live streaming up to HD video to the internet via Ethernet output. It features a USB output that allows you to record the program output as well as record the individual HDMI inputs to an external USB drive (not included). In addition to recording the program stream and individual inputs, the ATEM Mini Pro ISO also records the embedded audio and analog audio inputs, generating a DaVinci Resolve project file of your live stream. This allows you to take your live production into DaVinci Resolve to make tweaks or adjustments using the source material that is already on your USB drive.

Key Specs

Available M/E Layers	5 M/E
Effect Types	1x DVE, Graphic, Transition, Chroma Key, Alpha Key, Luma Key
Downstream Keys	1x Chroma, DVE 2x Luma
Generators	1x Pattern 2x Color
Audio Mixing	2-Channel Mixing

Processing

Switching Type	Pushbutton
Color Processing	10-Bit 4:2:2 YUV

Input

Number of Video Input Sources	4
Video Inputs	4x HDMI Female
Input Video Format	HDMI (10-Bit 4:2:2 YUV) 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps 1080i 50/59.94/60 fps 720p 50/59.94/60 fps
Audio Inputs	2x 1/8" / 3.5 mm TRS Stereo Analog Female
Input Audio Format	Analog
Embedded Audio Input	HDMI: 2-Channel (per Input)

Output

Video Output Channels	1
Video Outputs	1x HDMI
Output Video Format	HDMI / RJ45 (10-Bit 4:2:2 YUV) 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps
Embedded Audio Output	HDMI: 2-Channel (per Output)
Multiview Output	Yes
Monitor Output	1x HDMI

Connectivity

Other I/O	1x RJ45 Control, Firmware, LAN, Sync, Tally, Timecode Input/Output 1x USB-C Control, Firmware Input/Output
IP Video	H.264: 1920 x 1080 at 23.98p, 24p, 25p, 29.97p, 30p, 50p, 59.94p, 60p Encoding
Transport Protocols	RTMP
Simultaneous Streams	1 Streams

Hardware

OS Compatibility	macOS 10.14 or Later / Windows 10 or Later
OS Compatibility	macOS 10.14 or Later Windows 10
Processor	Not Specified by Manufacturer
Wi-Fi	No
Bluetooth	No
Power I/O	1x Barrel (12 VDC ) Input
Power Consumption	36 W

General

Operating Conditions	41 to 104°F / 5 to 40°C up to 90% Humidity
Storage Conditions	14 to 140°F / -10 to 60°C
Dimensions	9.35 x 4.07 x 1.38" / 23.75 x 10.34 x 3.51 cm
Weight	19.4 oz / 550 g

Packaging Info

Package Weight	2.29 lb
Box Dimensions (LxWxH)	11.2 x 6.5 x 4.6"

What's in the Box:

Blackmagic Design ATEM Mini Pro ISO HDMI Live Stream Switcher
12V Power Supply with International Adapters
Limited 1-Year Warranty
