PreSonus  |  SKU: REVELATOR IO44

PreSonus Revelator io44 Ultracompact 4x2 USB Type-C Audio Interface

Dhs. 749.00
Tax included Shipping calculated at checkout.

Delivery and Shipping

We offer free delivery across the UAE for orders over 250 AED.

For orders below this amount delivery fee of AED 29.00 will apply.

• Dubai: Delivery within 1 working day.

• Rest of UAE: 1-2 working days.

• GCC: We also provide shipping to countries within the GCC, but delivery times may vary depending on location.

  • Credit card & Tabby
  • Cash on Delivery (COD) is available only for orders within the UAE.

Description

Key Features

  • Podcasters, Streamers, and Musicians
  • USB Type-C Connectivity
  • Mic/Instrument Preamp, Stereo Line Input
  • 1 Headphone/Headset Port, 2 Main Outs
  • 24-Bit / 96 kHz Converters
  • Bus Powered / Mac, Windows
  • Phantom Power for Condenser Mics
  • Onboard DSP with Versatile Presets
  • 2 Dedicated Loopback Channels
  • DAW, VIs, Plug-Ins, Loops, and Samples

Overview

Loaded with onboard DSP, loopback channels, and surprisingly versatile I/O in a highly portable and compact form factor, the PreSonus Revelator io44 USB Type-C audio interface blends studio-quality, sonic performance, and refreshing ease of use, so podcasters, live streamers, content creators, and musicians can get great sounds in a hurry. Plus, it comes with a powerful software package that includes a DAW, a slew of virtual instruments, plug-in effects, loops, samples, and much more.

On the hardware side, the single XMAX-L preamp and 24-bit / 96 kHz converters deliver clarity and natural tonality for your microphone or electric guitar, while the separate mini-jack input accommodates a line-level source such as a DJ mixer. Whether you use the factory presets or create your own, the built-in Fat Channel processing offers pro-level impact without ever taxing your computer. Use the two loopback channels and integrated mixer to pipe in backing tracks or a call-in guest, and feed independent mixes to the main and headphone outputs.

Key Specs

Channels of I/O
4 Inputs / 2 Outputs
Maximum Sampling Rate
96 kHz / 24-Bit
Number of Microphone Inputs
1
Analog Audio I/O
1x Combo XLR-1/4" TS Balanced/Unbalanced Mic/Hi-Z Input
1x 1/8" / 3.5 mm TRS Unbalanced Line Input
1x 1/8" / 3.5 mm TRRS Unbalanced Headset In/Out
2x 1/4" TRS Balanced Monitor Output
Digital Audio I/O
No
Host Connection
1x USB-C
OS Compatibility
macOS 10.13 or Later
Windows 10 or Later
Chrome OS
iPadOS
Power Requirements
USB Bus Power
Channels of I/O
4 Inputs / 2 Outputs
Built-In DSP
Yes
Maximum Sampling Rate
96 kHz / 24-Bit
Number of Microphone Inputs
1
Built-In Microphone
No
Input Level Adjustment
1x Knob
Signal Processing
Pad
No
Gain/Trim Range
Mic Inputs:
60 dB
Hi-Z Inputs:
50 dB
Line Inputs:
40 dB
High-Pass Filter
24 to 1000 Hz, 12 dB/Octave (via Software)
Solo/Mute
Mute per Master
Connectivity
Analog Audio I/O
1x Combo XLR-1/4" TS Balanced/Unbalanced Mic/Hi-Z Input
1x 1/8" / 3.5 mm TRS Unbalanced Line Input
1x 1/8" / 3.5 mm TRRS Unbalanced Headset In/Out
2x 1/4" TRS Balanced Monitor Output
Phantom Power
48 V, Selectable On/Off
Digital Audio I/O
No
Host Connection
1x USB-C
Host Connection Protocol
USB 2.0
USB (Non-Host)
No
Sync I/O
No
Network I/O
No
MIDI I/O
No
Expansion Slots
No
Wireless
No
Performance
Frequency Response
Mic, Line, Hi-Z Inputs:
20 Hz to 20 kHz +0.1/-0.3 dB (Unity Gain)
Monitor Outputs:
20 Hz to 20 kHz +0.1/-0.5 dB (Unity Gain)
Headphone Outputs:
20 Hz to 20 kHz +0.1/-0.3 dB (Unity Gain)
Maximum Input Level
Mic/Hi-Z Inputs:
+10 dBu (Min Gain)
Line Inputs:
+10 dBu (Balanced, Unity Gain, 1 kHz)
Maximum Output Level
Monitor Outputs:
+10 dBu
Headphone Output Power
30 mW per Channel into 56 Ohms
Impedance
Mic Inputs:
1.4 Kilohms (Balanced)
Hi-Z Inputs:
750 Kilohms
Headphone Outputs:
32 to 300 Ohms
Dynamic Range
AD/DA Converters:
96 dB
THD+N
Mic Inputs:
0.005% (1 kHz, Min Gain, -1 dBFS Input)
Monitor Outputs:
0.003% (1 kHz, at 0 dBFS)
EIN
Mic Inputs:
-128 dBu A-Weighted (150-Ohm Source, Max Gain)
Digital Audio
Sample Rates
44.1 / 48 / 88.2 / 96 kHz
Sample Rate Conversion
No
Bit Depths
24-Bit
Latency
Zero-Latency Direct Monitoring
Sync Sources
Internal
Audio Storage & Playback
Media/Memory Card Slot
No
Compatibility
OS Compatibility
Computer: macOS 10.13 or Later / Windows 10 or Later / Chrome OS
Mobile: Android/iOS
OS Compatibility
macOS 10.13 or Later
Windows 10 or Later
Chrome OS
iPadOS
RAM Requirements
4 GB
Storage Requirements
200 MB
Mobile App Compatible
Yes: Android & iOS
Mobile Device Compatibility
iPad
iPad Air
iPad Mini
iPad Pro
iPhone
iPod Touch
Android Smartphone
Android Tablet
Required Hardware
Available USB-A Port
USB Cable (Included)
Power
Power Requirements
USB Bus Power
Physical
Dimensions
5.35 x 3.03 x 2.3" / 13.59 x 7.7 x 5.8 cm
Weight
0.8 lb / 0.4 kg
Packaging Info
Package Weight
1.335 lb
Box Dimensions (LxWxH)
6.9 x 5 x 4.9"

What's in the Box:

  • PreSonus Revelator io44 Ultracompact 4x2 USB Type-C Audio Interface
  • USB Type-C to USB Type-A Cable (3.3')
  • Limited 1-Year Manufacturer Warranty
